Ievietojiet NS-DN25 ar atloku 50,8 m SFLNS252045

Name: Ievietojiet NS-DN25 ar atloku 50,8 m SFLNS252045
Brand: Alfagomma
SKU: SFLNS252045
Price: 54.93 EUR
Availability: BackOrder

Apmaksas iespējas

54,93 €

AR PVN

Pēc pieprasījuma

Ievietojiet NS-DN25 ar atloku 50,8 m SFLNS252045 Alfagomma

Uz pasūtījumu

ID: 90046

Apraksts

Part number	SFLNS252045
EAN
Unit	Each
Long description	Alfagomma No-Skive press fittings (type 'NS') are designed for use in combination with Alfabiotech high-pressure hoses.
Pros	Press fittings help ensure faster and easier hose assembly and help to save costs. Processing produces less dirt, smell and waste. No special tool needed to skive the hose.
Product details	The Alfagomma No-Skive press fitting is used in combination with Alfabiotech high-pressure hoses. With these press fittings, there is no need to skive the inner and outer casing.
Angle	45 °
Connection 2, diameter	1 Inch
Connection 2, diameter	25 mm
Connection 2, type	Hose end
Connection 2, type - male/female	Male
Connection no 1 center to end distance	88.9 mm
Connection no 1 diameter	1 Inch
DConnection no 1 length	32.5 mm
Connection no 1 type - male/female	Male
Connection no 1 type	Flange
FDFlange outside diameter	50.8 mm
Flange standard pressure series	3000
Max working pressure	345 BAR
Original number equivalent	H1343340-162000
Shape	Elbow - 2 connection sides
